Description

Maximum current: 100A

Voltage：3.3-5V

temperature：-41°C ~ 152°C

Industry-leading noise performance through proprietary amplifier and filter design techniques

Integrated shield greatly reduces capacitive coupling from current conductor to die due to high dV/dt signals, and prevents offset drift in high-side, high voltage applications

Total output error improvement through gain and offset trim over temperature

Small package size, with easy mounting capability

Monolithic Hall IC for high reliability

Ultra-low power loss: 100 μΩ internal conductor resistance

Galvanic isolation allows use in economical, high-side current sensing in high voltage systems

3.0 to 5.5 V, single supply operation

120 kHz typical bandwidth

3 μs output rise time in response to step input current

Output voltage proportional to AC or DC currents

Factory-trimmed for accuracy

Extremely stable output offset voltage

Nearly zero magnetic hysteresis
